12kW Commercial Wallbox EV Charger <br> (EV-ACT5004T)

Home Products AC Home Chargers

12kW Commercial Wallbox EV Charger
(EV-ACT5004T)

12kw

1 Phase

50A

The EVDANCE 12kW 1-phase EV charger delivers powerful, reliable charging for house. Featuring dynamic load balancing and solar PV integration, it optimizes energy use, cuts costs, and meets sustainability goals. Its rugged IP66 design ensures durability in domestic environments.

Message

Product application

Enjoy Flexible Deployment

The EVDANCE Series offers two versions: wall-mount and portable. While the wall-mount unit is tailored for commercial enterprises, both provide adaptable and convenient charging solutions.
Safe & Fast Charging

Compliant with OCPP 1.6J and rigorous global safety standards, the EVDANCE Series ensures reliable operation. Its multi-layered security and high-level protection effectively safeguard user data and connected devices.

Key Benefits

Advantages

High-Efficiency Charging

High-power intelligent output

3x faster than industry standards

Energy-efficient performance

Uncompromising Safety

Military-grade protection system

Auto-shutdown for overloads/errors

Enhanced safety engineering

Smart Digital Control

Real-time charging monitoring

Remote start/stop via app

Detailed usage analytics

Custom Branding Ready

White-label OEM/ODM support

Custom colors & designs

Scalable commercial solutions

Product parameters

EVDANCE 12kW AC Home Charger

Technical Specifications

Performance Resilience Connectivity Certifications

Maximum Charging Power

12kW (1-Phase)
Rated Current

50A Adjustable
Charge Connector

Type 1/Sae J1772
Cable

25FT/7.6m
Plug

Custom
Start Mode

Plug-to-Play / RFID / App

IP Rating

IP66
Operating Temp

-30℃ to +50℃
Storage Temp

-40℃ to +85℃
Enclosure

PC+TPU
Installation

Portable
Package Dimension

40*12.5*33.6cm (LWH)
Weight

5.41kg

RFID

Mifare ISO/IEC14443A
Communication

Wi-Fi, Ethernet, Bluetooth
4G

Optional
OCPP

1.6 Json
LED

Tri-Color Status

Safety

RCD Type A + DC 6mA
Compliance

CE, RoHS
Standard

EU 2014/94/EU
Warranty

1 Year

Give 12KW 50A Single-Phase EV Charger Common combination, the choice of most households to convert daily collected clean energy into household electricity expenses

RECOMMEND POPULAR PRODUCTS

22kw Commercial Portable EV Charger
(EV-ACS3207PE)

22kw

3 Phase

32A

22kW Premium charging
150km/45min Top-Up Loyalty Integration*
Blends with luxury environments
Point redemption & POs sync
Enhanced guest experience

Discover More

22kW Commercial Wallbox EV Charger
(EV-ACT3202PE)

22kw

3 Phase

32A

150km/45min Top-Up Loyalty Integration*
Blends with luxury environments
Point redemption & POs sync
Enhanced guest experience

Discover More

12kW Commercial Wallbox EV Charger
(EV-ACT5003U)

12kw

1 Phase

50A

12kW Green Energy Charging
Solar/Wind Synced 35% Carbon Reduction*
Auto-adjusts to renewable supply
Off-peak energy storage
Weatherproof lP66 housing

Discover More

Certification-Focused

Certified Performance Excellence Rigorous Validation by Global Authorities

IP66 Validation

Submerged 1m/30min (IEC 60529)
Arctic Endurance

-40℃ cold start (EN 60068-2-1)
Salt Spray Resistance

1,000hrs (ISO 9227)
Surge Protection

6kV lightning test (IEC 61000-4-5)

Frequently Asked Questions

Global Buyers' Top Concerns

01

What's delivery time?

Stock: 3 days (US/EU warehouses). Custom:7 days. Air freight for emergencies.
02

Do you provide custom branding?

OEM services available: Custom logos/colors + certification support. MOQ 100 units.
03

Can I monitor remotely?

Yes: Track usage & costs via app/web. Integrates with Fleetio/Geotab for fleet management.
04

Is it compatible with my EV?

Works with all brands (Tesla, BYD, VW etc.) using Type 1/2/CCS connectors. OCPP 1.6J enables plug-and-charge.
05

What charging speeds do you offer?

Commercial-grade power (3.7-22kW+) with 3x faster charging than standard units. Intelligent grid adjustment ensures optimal performance.
